+ DWG · SH 1 / 5PROJECT · MARINA CENTRE RETROFITREV · 14
PE-SIGNED · MARINA CENTRE · 2024
PROJECT TITLE
Greenstone Engineering
M&E consulting engineers for commercial + light industrial
DrawnDrawn by teamCheckedMech. PEYear1989OfficeJurong
P.E.0Assoc.0Projects0+StatusACTIVE
Mechanical and electrical consulting engineers since 1989. We have designed M&E systems for commercial offices, light industrial buildings, and laboratories across Singapore and the region. 110 active projects, BCA-registered, ACES member firm.
Section drawing · Lvl 04 typical
Sheet 1A / 5· HVAC supply · 600×300· LV conduit · 32mm· AHU-04
Mechanical · HVAC Electrical · LV + BMS Junction nodeScroll-driven section view · indicative
Structural GA · erection sequence
Sheet 1B / 50 mm c/c0 mm· UB 457×191 primary
Design load
0.5 kPa
Clear span
0.4 m
Fab. tolerance
± 0 mm
Members
0 no.
Primary steel Secondary + bracingScroll-driven erection sequence · indicative
Disciplines.
Sheet 2 / 5D-01
Mechanical engineering
HVAC, plumbing, fire protection, energy modelling. Code compliance through completion.
D-02
Electrical engineering
Power, lighting, low-voltage, BMS integration, energy efficiency design.
D-03
Sustainability consulting
Green Mark Platinum, LEED, energy audits, retrofitting older buildings to current standards.
D-04
Project supervision
On-site supervision during construction and commissioning, including coordination with builders and authorities.
+ CALC · SH 5 / 5FORM CE-04 · LOAD CALCULATION WORKSHEETREV · 14
Parameter
Input from brief
Load
Building type
Commercial / light industrial
0
Vintage
1995 to 2010 stock
0
GFA
1,200 to 8,500
0
Scope
M&E retrofit + Green Mark
0
Σ Consultation load
indicative · refined on the call
0
Next PE-led scope call · tolerance ±30min
ReadingTHU 06 JUN·0945h± 0030
One PE on the line, thirty minutes, no business-dev intermediary. The PE who takes the call is the PE who will sign the drawings.
CHKMech. PE · countersigned
CERTBCA + ACES registered
EST1989 · Jurong office
